Features
WorkCentre 6505 Color Laser Multifunction Printer
User Guide
19
Rear View
Internal View
1. Power plug
2. ADF cover
3. USB port
4. Memory slot door
5. Network connector
6. Line out (to telephone)
7. Line in (from wall jack)
1. Button for opening the front cover
2. Transfer unit
3. Imaging unit
4. Fuser
5. ADF document glass
6. Toner cartridges
wc6505_004
2
1
4
5
6
7
3
wc6505_005
1
2
3
4
5
6
