Yamaha WaveRunner FX SHO Service Manual

5-80
E
POWR
1
2
3
4
5
6
7
8
9
Generator cover and flywheel magneto
Generator cover and flywheel magneto removal
Step
Procedure/Part name
Q’ty Service points
1Plug 1
2 Drive coupling 1
3 Washer 1
4 Plastic tie 1
5Grommet 2
6 Bolt/washer 2/2
7Bracket 2
8 Clamp/hose 1/1
9Bolt 9
10 Clamp 1
11 Generator cover assembly 1
12 O-ring 1
Not reusable
13 Dowel pin 2
13
2
8
7
6
3
1
4
5
9
8
6
6
10
9
7
12
19
18
14
16
a
15
21
11
20
LT
572
LT
242
E
120 N
·
m (12.0 kgf
·
m, 88.5 ft
·
Ib)
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
6 × 20 mm
80 N
·
m (8.0 kgf
·
m, 59.0 ft
·
Ib)
26 N
·
m (2.6 kgf
·
m, 19.2 ft
·
Ib)
8 × 50 mm
LT
572
LT
572
24 N
·
m (2.4 kgf
·
m, 17.7 ft
·
Ib)
8 × 20 mm
E
E
AA
17
17
Generator cover and flywheel magneto

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
