Yamaha WaveRunner FX SHO Service Manual

5-82
E
POWR
1
2
3
4
5
6
7
8
9
Generator cover disassembly
Step
Procedure/Part name
Q’ty Service points
1Bolt 2
2Bolt 1
3 Washer 1
4Bolt 3
5Bolt 2
6Clamp 1
7 Stator coil assembly 1
8 Oil seal 1
Not reusable
9 Circlip 1
10 Bearing 1
Not reusable
11 Generator cover 1
Reverse the disassembly steps for
assembly.
8
9
10
11
3
2
1
7
4
6
5
LT
242
AA
AA
E
LT
242
15 N
·
m (1.5 kgf
·
m, 11.1 ft
·
lb)
6 × 15 mm
5 N
·
m (0.5
kgf
·
m, 3.7 ft
·
Ib)
5 × 15 mm
LT
242
5 N
·
m (0.5
kgf
·
m, 3.7 ft
·
Ib)
5 × 10 mm
15 N
·
m (1.5 kgf
·
m, 11.1 ft
·
lb)
6 × 30 mm
LT
242
EP
Generator cover and flywheel magneto

Yamaha WaveRunner FX SHO Specifications

General

Manufacturer	Yamaha
Model	WaveRunner FX SHO
Category	Personal Watercraft
Engine Type	4-cylinder, 4-stroke, Supercharged
Displacement	1812cc
Bore x Stroke	86mm x 78mm
Fuel Delivery	Electronic Fuel Injection
Horsepower	210 HP
Starter System	Electric
Lubrication System	Wet sump
Length	132.7 in (3.37 m)
Fuel Capacity	18.5 gal (70 L)
Oil Capacity	5.3 qt (5.0 L)
Rider Capacity	3 persons
Cooling System	Water-cooled
Width	1.23 m
Dry Weight	377 kg
