8-22
E
HULL
HOOD
1
2
3
4
5
6
7
8
9
Steering console cover
Multifunction meter and cover removal
Step
Procedure/Part name
Qty Service points
Handlebar assembly Refer to Handlebar assembly removal.
Service lid Refer to Front hood removal.
1Rivet 2
2 Cover 1
3 Plastic tie 1
4 Multifunction meter coupler 4
5Screw 4
6 Multifunction meter cover 1
7 Left operation button coupler 1
8 Right operation button coupler 1 FX Cruiser SHO
11
10
14
4
1
2
5
8
12
3
7
9
6
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
5 × 15 mm
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
5 × 12 mm
13
Steering console cover
