Configuring Basic Features
359
3. Enter the group call pickup code in the Group Call Pickup Code field.
4. Click Confirm to accept the change.
To configure a group pickup key via phone user interface:
1. Press Menu->Features->DSS Keys.
2. Select the desired DSS key.
3. Press or , or the Switch soft key to select Key Event from the Type field.
4. Press or , or the Switch soft key to select GPickup from the Key Type field.
5. Press or , or the Switch soft key to select the desired line from the Account
ID field.
6. (Optional.) Enter the string that will appear on the LCD screen in the Label field.
7. Enter the group call pickup code in the Value field.
8. Press the Save soft key to accept the change.
Call pickup is implemented through SIP signals on some specific servers. When this
feature is enabled, IP phones support picking up incoming calls via the INVITE message
which includes a Replaces header in the message body. The value of Replaces is
derived from a NOTIFY message with dialog-info event. A user can pick up an incoming
call by pressing the DSS key used to monitor a specific extension (such as the BLF key).
For more information on BLF, refer to Busy Lamp Field (BLF) on page 445.
If the visual alert for blf pickup feature is enabled, a user can also pick up an incoming
call by pressing the DPickup soft key. For more information on visual alert for blf pickup,
refer to Visual Alert and Audio Alert for BLF Pickup on page 447.
It is not applicable to SIP-T19(P) E2 and CP860 IP phones.
Note
In this way, you do not need to configure the directed call pickup code.
