Configuring Security Features
737
AES keys must be 16 characters and the supported characters contain: 0-9, A-Z, a-z
and the following special characters are also supported: # $ % * + , - . : = ? @ [ ] ^
_ { } ~.
3. Click Confirm to accept the change.
To configure AES keys via phone user interface:
1. Press Menu->Settings->Advanced Settings (default password: admin) ->Set AES
Key.
2. Enter the values in the Common AES Key and MAC-Oriented AES Key fields.
AES keys must be 16 characters and the supported characters contain: 0-9, A-Z, a-z
and the following special characters are also supported: # $ % * + , - . : = ? @ [ ] ^
_ { } ~.
3. Press the Save soft key to accept the change.
IEEE 802.1X authentication is an IEEE standard for Port-based Network Access Control
(PNAC), part of the IEEE 802.1 group of networking protocols. It offers an authentication
mechanism for devices to connect/link to a LAN or WLAN. The 802.1X authentication
involves three parties: a supplicant, an authenticator and an authentication server. The
supplicant is the IP phone that wishes to attach to the LAN or WLAN. With 802.1X
port-based authentication, the IP phone provides credentials, such as user name and
password, for the authenticator, and then the authenticator forwards the credentials to
the authentication server for verification. If the authentication server determines the
credentials are valid, the IP phone is allowed to access resources located on the
protected side of the network.
IP phones support protocols EAP-MD5, EAP-TLS, EAP-PEAP/MSCHAPv2,
EAP-TTLS/EAP-MSCHAPv2, EAP-PEAP/GTC, EAP-TTLS/EAP-GTC and EAP-FAST for 802.1X
authentication.
