Yealink VCM38 Administrator's Guide

| Getting Started | 33
Left Side of VCH51 Cable Hub
Port Name Description
1 PC port Connect to PC via Type-C cable for content sharing.
2 HDMI Connect to PC via HDMI cable for sharing contents.
Right Side of VCH51 Cable Hub
Port Name Description
1 PoE Connect to the VC Hub/Phone port on the VCS codec or to
the PoE.
CP960 Conference Phone
You can use CP960 conference phone as a microphone and a speaker when you are having a call on
VC200/VC200-E/VC500/VC800/VC880/PVT980/PVT950. You can also place calls, answer calls or view
directory and history on CP960.

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
