Yealink VCM38 Administrator's Guide

| Getting Started | 41
CP900/CP700 Ultra-Compact Speakerphone
After you connect CP900/CP700 to VP59 via a USB cable, VP59 will automatically take CP900/CP700 as
audio input or output device. You can use CP900/CP700 to control the call on VP59, adjust the volume,
and set the mute status.
Name Description
1 Microphone Provide optimal voice pickup performance.
2 Bluetooth Button Enable/disable the Bluetooth. Tap it for 2 seconds
to enable the pairing mode, then CP900/CP700 can
search for and connect to a device. Double-tap to
disconnect. Tap again to reconnect.
3 Volume Down Tap to turn down the volume.
Note: If you do not use the handset and
headset, the volume of CP900/CP700 is
synchronized with the one of VP59.
4 Answer Call Answer the call; tap it for 6 seconds to reset CP900/
CP700 to factory.
5 Power On/Off Power on/off CP900/CP700.
6 Mute Key Mute/unmute the microphone.
Note: If you do not use the handset and
headset, the mute status of CP900/CP700 is
synchronized with the one of VP59.
7 Volume Up Tap to turn up the volume.
Note: If you do not use the handset and
headset, the volume of CP900/CP700 is
synchronized with the one of VP59.
8 End Call Hand up the call or reject an incoming call; tap it for 6
seconds to reset CP900/CP700 to factory.
8 Voice Assistant Button Enable the voice assistant.

Yealink VCM38 Specifications

General

Type	Conference microphone
Noise reduction	Yes
Microphone frequency	100 - 16000 Hz
Microphone sensitivity	-45 dB
Microphone pick-up range	6 m
Number of microphone arrays	8
Maximum sound pressure level (1kHz)	100 dB
Device interface	RJ-45
Connectivity technology	Wired
Maximum operating distance	40 m
Mounting type	Ceiling
Product color	Silver
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Number of products included	1 pc(s)
Harmonized System (HS) code	85181000
Power source	DC/PoE
Sustainability certificates	CE, Federal Communications Commission (FCC), REACH, RoHS

Weight and Dimensions

Width	127.3 mm
Height	66.3 mm
