Chapter 8 - Fieldbus communication (option)
8:1.3.1 Binary input telegram
To PLC from Softstarter.
Word in
input
data area
Binary
input
byte
Bit Data Description
0 0 0 K4 relay output Status of K4
1 K5 relay output Status of K5
2 K6 relay output Status of K6
3
V7 Programmable software
output
Status of V7
4 Start Input Status of Start Input
5 Stop Input Status of Stop Input
6 In0 Input Status of In0
7 In1 Input Status of In1
1 8 (0) Run Run Status
9 (1) Top Of Ramp Top Of Ramp Status
10 (2)
Line or Inside Delta
connection
0 = Line, 1 = Delta
11 (3) Phase sequence 0 = L1,L2,L3 1=L1,L3,L2
12 (4) Prot Motor OL Event Status
13 (5) Prot Locked Rot Event Status
14 (6) Prot Underload Event Status
15 (7) Prot Phase Imb Event Status
1 2 0 Prot High I Event Status
1 Prot Phase Rev Event Status
2 Prot PTC Event Status
3 Fault ByPass Event Status
4 Prot SCR OL Event Status
5 Warn OL Event Status
6 Warn SCR OL Event Status
7 Warn I=High Event Status
3 8 (0) Warn I=Low Event Status
9 (1) Fault (general signal)
Event Status, general for all
faults
10 (2) Fault Phase Loss Event Status
11 (3) Fault SC SCR Event Status
12 (4) Fault Open SCR Event Status
13 (5) Fault Wrong Freq Event Status
14 (6) Fault Connection Event Status
15 (7) Fault Internal Event Status
2 4 0 Fault FB Timeout Event Status
1 Fault HS Temp Event Status
