Chapter 7 - Settings and configuration
Figure 23: Functional Settings menu
Top level
Settings
Application setting
Basic settings
Functional settings
Presentation settings
Service settings
All settings
Changed settings
Reset all settings
Seq. Start
Settings
Functional settings
Start / Stop
Protections
Warnings
Faults
Inputs
Outputs
Fieldbus
Figure 24: Start/Stop group
7:2.4 Functional Settings
The Functional setting menu consists of groups with param-
eters arranged by function such as protection, warning, fault,
fieldbus communication etc. This menu should be used if a
more advanced set-up is required. For a detailed description
of each parameter, see Chapter 10 “ Functions” .
Enter the Functional settings
Enter the menu by selecting Functional Settings .
7:2.4.1 Start/Stop
To set parameters related to start and stop, enter the Start/
Stop group. The following parameters are available in this
group:
• Setting I
e
• External By-Pass
• Start ramp
• Stop ramp
• Initial voltage
• End voltage
• Step down voltage
• Current limit level
• Kick start
• Kick level
• Kick time
• Start range
• Stop range
To set parameters from Setting I
e
to Current limit level, see
“Basic Settings”.
