Chapter 7 - Settings and configuration
7:2.2 Application Setting
The Application setting menu consists of predefined param-
eters for the selected application and should be used if an
easy and quick set-up is required. Only a few parameters
need to be set to allow the start of the motor. All necessary
input data will show up in an automatic loop.
Enter the Application setting
Enter the menu by selecting Application Setting .
Select what type of application the softstarter is used for by
pressing Store Set . If the desired application is not listed,
select the one closest to the application and choose Tune
Set (see below). Possible applications are:
• Centrifugal Pump
• Hydraulic Pump
• Centrifugal Fan
• Axial Fan
• Compressor
• Conveyor
• Crusher
• Mixer
• Bow Thruster
Confirm the selected application by pressing Next . If the
wrong application type was selected, press Back and select
the correct type.
Figure 11: Application setting menu
Figure 12: Application type
Figure 13: Application type
Figure 10: Application setting menu
Application Setting
Select
Centrifugal Pump
Store Set Back
Centrifugal Pump
Next Back
Top level
Settings
Application setting
Basic settings
Functional settings
Presentation settings
Service settings
All settings
Changed settings
Reset all settings
