Chapter 7 - Settings and configuration
Figure 28: Inputs group
Seq. Start
Settings
Functional settings
Start / Stop
Protections
Warnings
Faults
Inputs
Outputs
Fieldbus
7:2.4.5 Inputs
To set parameters related to the programmable inputs,
enter the Inputs group.
First programmable input (In0)
Select the required function for the input In0.
Press
Store
to save/activate the selected function.
One of the following functions can be selected:
None No specific function (not activated).
Reset Reset of a fault or overload condition.
Enable When In0=0 the softstarter stops immedi-
ately.
When In0=1 the softstarter is in normal
operation.
Overrides all other inputs.
Jog Performs a start ramp until command is
released. The motor stops immediately
when the input is opened.
DOL Open/close the bypass contactor
(PSTB370...PSTB1050).
Start2 Start signal for 2nd parameter set-up.
Press
Store
to save/activate the selected function.
