ABB PST User Manual

Low Voltage Products & Systems 109
ABB Inc. • 888-385-1221 • www.abb-control.com AC 1006.9 - 5/03
Chapter 8 - Fieldbus communication (option)
8:1.3.8 Parameters
No Type Parameter Description Ran
g
eUnit
1 Read/Write Setting Ie Setting current 0 – 3000 (*) Amp
2 Read/Write Start Ramp Time for start ramp 1 – 120 Sec
3 Read/Write Stop Ramp Time for stop ramp 0 – 120 Sec
4 Read/Write Init Volt Initial voltage for start ramp 30 – 70 %
5 Read/Write End Volt End voltage for stop ramp 30 – 70 %
6 Read/Write Step Down
Voltage value to which the softstarter
shall step down at stop and where it
shall commence the stop ramp.
30 – 100 %
7 Read/Write Current Lim Level of the current limit. 2.0 – 5.0 x Ie
8 Read/Write Kick Start Selection of Kick start No, Yes
9 Read/Write Kick Level Level of Kick start if selected 50 – 100 %
10 Read/Write Kick Time Time for Kick start if selected 0.1 – 1.5 Sec
11 Read/Write Start Range Selectable range for start ramp 1-30s, 1-120s
12 Read/Write Stop Range Selectable range for stop ramp 0-30s, 0-120s)
13 Read/Write Overload Overload protection No, Normal, Dual
14 Read/Write OL Class Overload Class 10A, 10, 20, 30
15 Read/Write OL Class S Overload Class, Dual type, Start Class 10A, 10, 20, 30
16 Read/Write OL Class R Overload Class, Dual type, Run Class 10A, 10, 20, 30
17 Read/Write OL Op
Type of operation for overload
protection
Stop– M, Stop– A, Ind
18 Read/Write Locked Rotor Locked rotor protection No, Yes
19 Read/Write Lock R Lev Trip level for locked rotor protection 3.0 – 8.0 x Ie
20 Read/Write Lock R Time Trip time for locked rotor protection 0.2 – 10.0 Sec
21 Read/Write Lock R Op
Type of operation for locked rotor
protection
Stop– M, Stop– A, Ind
22 Read/Write Underload Underload protection No, Yes
23 Read/Write Underl Lev Trip level for Underload protection 0.4 – 0.8 x Ie
24 Read/Write Underl Time Trip time for Underload protection 1 – 30 Sec
25 Read/Write Underl Op
Type of operation for Underload
protection
Stop– M, Stop– A, Ind
26 Read/Write Phase Imb Phase imbalance protection No, Yes
27 Read/Write Ph Imb Lev
Trip level for phase imbalance
protection
10 – 80 %
28 Read/Write Ph Imb Op
Type of operation for phase imbalance
protection
Stop– M, Stop– A, Ind
29 Read/Write High I High current protection No, Yes
30 Read/Write High I Op
Type of operation for high current
protection
Stop– M, Stop– A, Ind
31 Read/Write Phase Rev Phase reversal protection No, Yes
32 Read/Write Ph Rev Op
Type of operation for phase reversal
protection
Stop– M, Stop– A, Ind
33 Read/Write PTC PTC protection No, Yes
