Chapter 7 - Settings and configuration
Figure 29: Outputs group
Seq. Start
Settings
Functional settings
Start / Stop
Protections
Warnings
Faults
Inputs
Outputs
Fieldbus
7:2.4.6 Outputs
To set parameters related to the programmable outputs,
enter the Outputs group.
Relay K4
Select the required function for output relay K4.
One of the following functions can be selected:
Run Run indication.
TOR Top of ramp indication.
Event Indication of selected event(s) . The following
events can be selected individually:
• Motor overload protection
• Fault
• High current protection
• SCR overload protection
• Locked rotor protection
• Underload protection
• Phase imbalance protection
• PTC protection
• Phase reversal protection
• Overload warning
• SCR overload warning
• High current warning
• Low current warning
Press Store to save/activate the selected function.
Relay K5
Select the required function for output relay K5.
One of the following functions can be selected:
Run Run indication.
TOR Top of ramp indication.
Event Indication of selected event(s), see relay K4.
Press Store to save/activate the selected function.
