58 Low Voltage Products & Systems
AC 1006.9 - 5/03 ABB Inc. • 888-385-1221 • www.abb-control.com
Figure 21: Local control menu
Chapter 6 - Human-Machine Interface (HMI)
6:2.4 Local Control menu
The Local Control menu is used to start or stop the motor
from the keypad. When local control is selected, the
softstarter can only be controlled by the keypad.
The previous type of control is activated when exiting local
control.
Three different selections are possible (see the table below).
Press navigation keys to view different types of local control.
The LOCAL CONTROL menu can not be entered if Se-
quence start is selected.
Once the motor has been started in this menu, it must first
be stopped before you leave the menu. If the motor is
already running when the menu is entered, it is possible to
leave the menu without stopping the motor.
Top level
Settings
Local Control
Start / Stop
Event Log
Status Information
Reset Events
Jog
DOL Start
Function Description
Start/stop
To start and stop the motor
with the keypad.
Jog
To run the motor as long as
Jo
is pressed.
DOL start
(PSTB370...PSTB105
0 only)
To start and stop the motor
with the built-in by-pass
contactor. (See Chapter 3
for AC3 ratings)
To Next Page
