Chapter 8 - Fieldbus communication (option)

8:1.3.3 Diagnostic inputs

There are 3 channels available for fieldbus related diagnostic messages. Each

channel consists of two bytes with an error code and the parameter number that

caused the error. The latest error is stored in channel 1, the second latest in

channel 2 and the third latest in channel 3. The binary output bit “reset active

diagnostics” is used to clear the diagnostic area.

Error Codes:

1 = Parameter Value out of range.

2 = Invalid parameter number.

3 = Write parameter when fieldbus control is not enabled

Word in input

data area

Diagnostic

ut word

Error Code Parameter number

12 0

Diagn. Channel 1, Error

Code

Diagn. Channel 1,

Parameter No

13 1

Diagn. Channel 2, Error

Code

Diagn. Channel 2,

Parameter No

14 2

Diagn. Channel 3, Error

Code

Diagn. Channel 3,

Parameter No
