Chapter 6 - Human-Machine Interface (HMI)
Figure 22: Start/Stop menu
6:2.4.1 Start/Stop the motor
Start
Enter the Start/Stop menu, Figure 22.
Select Start. The motor will now start and run according to
the set parameters.
Stop
Select Stop . The motor will stop according to the set
parameters. It is possible to press the stop command
during the start ramp if necessary.
6:2.4.2 Jog
Enter the Jog menu, Figure 23.
Select Jog. The motor will start and accelerate to rated
speed according to the set parameters as long as the Jog
command is activated.
The motor stops immediately as soon as the command is
released.
6:2.4.3 DOL start
(PSBT370...1050 only)
Start from the softstarter
If necessary, the motor can be started DOL (Direct On
Line/across the line) with the integrated by-pass contactor.
Select the DOL start menu, Figure 25.
Select DOL start to close the integrated by-pass contactor.
Select Stop to open the contactor.
Warning!
The rated motor current must never exceed the DOL
rating of the integrated by-pass contactor. See Chap-
ter 3 for AC3 ratings.
Figure 23: Jog menu
Figure 24: DOL start menu
Top level
Settings
Local Control
Start / Stop
Event Log
Status Information
Reset Events
Jog
DOL Start
Top level
Settings
Local Control
Start / Stop
Event Log
Status Information
Reset Events
Jog
DOL Start
Top level
Settings
Local Control
Start / Stop
Event Log
Status Information
Reset Events
Jog
DOL Start
