8:1.3.4 Binary output telegram
From PLC to Softstarter.
Word in
output
data area
Binary
output
byte
Bit Data Description
000
Start (1st par set if
Seq.start)
Commence a start when
signal is set. Start1 if
sequence start.
1Stop
Commence a stop when
signal is negated.
2 Reset Events
Reset signal for possible
events.
3 Enable
Enable, this bit must be set
for runnin
g
the motor.
4Jog
Perform Jog when signal is
set.
5DOLstart
Perform DOL start when
signal is set.
6
Start2 (2nd par set
Seq.start)
Start2 if sequence start.
7
Start3 (3rd par set
Seq.start)
Start3 if sequence start.
1 8 (0) Time synchronisation
Time synchronisation signal
that is used to synchronise
the local real time clock with
the time given as an analog
input telegram to the
softstarter. If the signal is “1”
and there is a difference
between the times, the local
real time clock is
synchronised.
9 (1) Reset active diagnostics
When set to “1” this will
reset the fieldbus diagnostic
area.
10 (2) Spare
11 (3) Spare
12 (4) Spare
13 (5) Spare
14 (6) Spare
15 (7) Spare
Chapter 8 - Fieldbus communication (option)
