Chapter 6 - Human-Machine Interface (HMI)
Figure 19: Top level
Figure 20: Settings menu
6:2.2 Top Level
Top Level contains general softstarter information, and the
menus can be reached from here.
Use the navigation keys to cycle through the various menus.
Press Select to enter a menu.
Press Back to return to previous state
6:2.3 Settings menu
The settings menu is used to set up the softstarter param-
eters for various applications.
Use the navigation keys to cycle through the various sub
menus.
Menu Description
Settings
Set up softstarter
parameters.
Local Control Control the softstarter.
Event Log
Present the Event Log,
faults, protections,
warnings.
Status Information
Present various
information.
Reset Events Reset of events.
Top level
Settings
Application setting
Basic settings
Functional settings
Presentation settings
Service settings
All settings
Changed settings
Reset all settings
Local Control
Event Log
Status Information
Reset Events
Function Description
Application setting
Predefined parameters for
typical applications.
Basic settings
The basic and most used
start/stop settings.
Functional settings
Parameters are arranged
by function
Presentation settings Language, date, time etc.
Service settings Service and repair settings
All settings
A list with all possible
settings.
Changed settings
A list of all changed
settings.
Reset all settings
Reset all settings to factory
default settings.
