1 Publication 2711-UM014B-EN-P
Chapter
10
Installing the PV900/1000 Terminals
Chapter Objectives
This chapter describes how to mount the PV900 and PV1000 terminals
in a panel or enclosure including:
• hazardous locations and enclosures
• required tools
• mounting dimensions
• clearances
• cutout dimensions
• installing the PV900/PV1000 terminal in a panel
Hazardous Locations
See the nameplate label on terminal for certifications on hazardous
locations.
The PV900/PV1000 terminals have an operating temperature code of
T4 (maximum operating temperature of 135
° C or 275° F). Do not
install the terminals in environments where atmospheric gases have
ignition temperatures less than 135° C (275° F).
Enclosures
The PV900/PV1000 terminal must be mounted in an environment that
provides IEC-1131-2 Pollution degree 2 protection.
Mount the terminal in a panel or enclosure to protect the internal
circuitry. The terminal meets NEMA Type 12/13 and 4X (indoor use)
ratings only when mounted in a panel or enclosure with the
equivalent rating.
Allow enough space within the enclosure for adequate ventilation.
Consider heat produced by other devices in the enclosure. The
ambient temperature around the terminals must be between 0° and
55° C (32° and 131° F).
ATTENTION
!
In Class 1, Division 2 Hazardous locations, the
PanelView terminal must be wired per the National
Electric Code as it applies to hazardous locations.
Peripheral equipment must also be suitable for the
location in which it is installed.
