1 Publication 2711-UM014B-EN-P
Chapter
12
Terminal Connections
Chapter Objectives
This chapter describes network and device connections for PanelView
terminals.
• wiring and safety guidelines
• Cable charts
• Remote I/O connections
• DH+ connections
• DH-485 connections
• RS-232 (DH-485) connections
• RS-232 (DF1) connections
• ControlNet connections
• DeviceNet connections
• EtherNet/IP connections
• PanelView 300 Micro connections
• Computer or printer connection to RS-232 serial port
Wiring and Safety
Guidelines
Use publication NFPA 70E, Electrical Safety Requirements for
Employee Workplaces when wiring the PanelView terminals. In
addition to the NFPA general guidelines:
• route communication cables to terminal by a separate path from
incoming power.
• where power and communication lines must cross, they should
cross at right angles. Communication lines can be installed in the
same conduit as low level DC I/O lines (less than 10 volts).
• grounding minimizes noise from Electromagnetic Interference
(EMI) and is a safety measure in electrical installations.
• use the National Electric Code published by the National Fire
Protection Association as a source for grounding.
IMPORTANT
Do not run signal wiring and power wiring
in the same conduit.
