1 Publication 2711-UM014B-EN-P
Chapter
5
Running Applications
Chapter Objectives
This chapter describes operating procedures common to most
applications:
Application Information
The application designer is responsible for documenting the operation
of an application. Before running the application, you should
understand what processes are being controlled and monitored.
Important Information for
PanelView 300 Micro
Operations
The Up/Down and Left/Right cursor keys on the PanelView 300 Micro
may be assigned as additional function keys. It is the responsibility of
the application designer to inform the operator of the assigned
functions.
If cursor keys are assigned as function keys, the following (applies to
the currently active screen):
• List Selectors and Increment / Decrement objects are disabled if
the Up or Down cursor keys are used as function keys.
• Simultaneous pressing of Left and Right cursor keys does not
cause the terminal to enter Configuration Mode if the Left and
Right cursor keys are assigned as function keys anywhere in the
application.
• If both the Left/Right cursor keys are used on a screen and more
than one cursor operated object is present on the screen, all of
the cursor operated objects must be assigned to a function key.
screen security alarms
push button operation printing
control lists time or date
numeric entry controls message displays
ASCII entry controls numeric data displays
screen selectors bar graphs
list indicators analog gauges
multistate indicators
ATTENTION
!
Do not press multiple touch screen objects at the
same time. Pressing multiple objects simultaneously
may result in unintended operation.
