12-2 Terminal Connections
Cable Charts
Refer to the following charts for a summary of PanelView terminal
connections to controllers and network interface modules.
Runtime Communication Cables - To Processors
Cables: PanelView to Processor
Protocol PanelView Standard Comm Port
SLC-500, 5/01, 5/02
CH1 RJ45
(DH-485)
SLC-5/03, 5/04, 5/05
CH0 (9-pin RS-232)
(DF1 or DH-485)
SLC 5/03
CH1 (RJ45)
(DH-485)
SLC 5/04
CH1 (DH+)
SLC 5/05
CH1 (ENET)
DF1
xxx16
xxx17
xxx18
RS-232 (DF1) Comm Port (8-pin Mini Din)
PanelView 300 Micro
2711-xxx18
N/A
1761-CBL-AP00 (1.5ft/0.5m)
1761-CBL-PM02 (6.5ft/2m)
2711-CBL-PM05 (16ft/5m)
2711-CBL-PM10 (32ft/10m)
N/A N/A N/A
RS-232 (DF1) Communication Port (9-pin)
PanelView 300 - 1400
2711-xxx16, 2711-xxx17
N/A
2711-NC13 (16ft/5m)
2711-NC14 (32ft/10m)
2706-NC13 (10ft/3m)
N/A N/A N/A
DH-485
xxx2
xxx3
xxx5
xxx9
xxx19
RS-232 (DH-485) Comm Port (8-pin Mini Din)
PanelView 300 Micro
2711-xxx19
use AIC+ Module
(1761-NET-AIC)
Connect to Port 1 or 2
1761-CBL-AP00 (1.5ft/0.5m)
1761-CBL-PM02 (6.5ft/2m)
2711-CBL-PM05 (16ft/5m)
2711-CBL-PM10 (32ft/10m)
use AIC+ Module
(1761-NET-AIC)
Connect to Port 1 or 2
N/A N/A
RS-232 (DH-485) Communication Port (9-pin)
PanelView 300 - 1400
2711-xxx5, 2711-xxx9
use AIC+ Module
(1761-NET-AIC)
Connect to Port 1 or 2
2711-NC13 (16ft/5m)
2711-NC14 (32ft/10m)
2706-NC13 (10ft/3m)
use AIC+ Module
(1761-NET-AIC)
Connect to Port 1 or 2
N/A
N/A
DH-485 Communication Port (RJ45)
PanelView 300 - 1400
2711-xxx2, 2711-xxx3
1747-C10 (6ft/2m)
1747-C11 (1ft/0.3m)
1747-C20 (20ft/6m)
use AIC+ Module
(1761-NET-AIC)
Connect to Port 3
1747-C10 (6ft/2m)
1747-C11 (1ft/0.3m)
1747-C20 (20ft/6m)
N/A N/A
DeviceNet
xxx10
DeviceNet Communication Port
PanelView 300 - 1400
2711-xxx10
to SLC 5/02
with 1747-SDN and
DeviceNet cable use 1747-SDN Module with DeviceNet cable
ControlNet
xxx15
ControlNet Communication Port
PanelView 550T - 1400
2711-xxx15
N/A not applicable - PanelView does not support SLC ControlNet configurations
EtherNet/IP
xxx20
Ethernet Comm Port
PanelView 550T - 1400
2711-xxx20
N/A N/A N/A N/A Ethernet cable
