1 Publication 2711-UM014B-EN-P
Appendix
A
Specifications
PanelView 300 Micro
Electrical
DC Power
Supply Voltage Limits
Power Consumption
11 to 30V dc (24V nominal)
2.5W maximum (0.105A @24Vdc)
Mechanical
Enclosure NEMA Type 12/13, 4X (Indoor use only), IP54,
IP65
Weight 284 grams (10 oz.)
Dimensions
mm
Inches
133 (H) x 112 (W) x 48 (D)
5.23 (H) x 4.38 (W) x 1.87 (D)
Installed Depth 35mm (1.39 inches)
Display
Type Liquid Crystal Display (LCD) with integral LED
backlight (100,000 hour life)
Size 73 mm (w) x 42 mm (h)
2.87 in. (w) x 1.67 in. (h)
Pixels 128 x 64
Terminal Memory
Total Application Flash Memory 240K bytes (application screens)
Environment
Operating Temperature 0 to 55° C (32 to 131° F)
Storage Temperature -20 to 85° C (-4 to 188° F)
Relative Humidity (non-condensing) 5 to 95% at 0 to 55° C (32 to 131° F)
Heat Dissipation 2.5 Watts (8.5 BTU/Hour)
Impulse Shock 30G operating, 50G nonoperating
Vibration (operating) 2G up to 2,000 Hz
