1-40 Terminal Overview
Replacement Parts
Backlight Lamps
Real Time Clock Modules
Panel Mount Clips and Studs
Remote I/O Connector
Power Input Connector
Catalog No. 550 600 900 1000 Description
2711-NL1 x Halogen backlight lamp for all PV550
terminals. Provides backlighting for LCD
display.
2711-NL2 x Backlight for PV900 color terminal.
2711-NL3 x Backlight for PV600 color terminal.
2711-NL4 x Backlight for PV1000 color terminal.
Catalog No. 300 550 600 900 1000 1400 Description
2711-NB2 x Real time clock module for PV550 (Series
D or earlier). Does not apply to the PV550
touch screen terminals. Contains lithium
battery.
2711-NB3 xxx x xReal time clock module for PV600, PV900,
PV1000, PV1400 or PV550 (Series E or
later). Does not apply to PV550/PV600
touch screen terminals. Contains lithium
battery.
2711-NB4 xxx Real time clock module for PV300 keypad,
PV550/PV600 touch screen only termi-
nals. Contains lithium battery.
Catalog No. 600 900 1000 1400 Description
2711-NP1 x 10 panel mount clips for PV1400 terminal.
2711-NP2 xxx 6 panel mount clips for PV600, PV900 or
PV1000 terminals.
2711-NP3 x Optional panel mount studs (18) for
PV1400 terminals.
Catalog No. 550 600 900 1000 1400 Description
22112-046-03 xxx x xTerminal block connector plugs into Remote I/O
port of Remote I/O terminals.
Catalog No. 300M Description
2711-TBDC x Removable DC power input connectors for PanelView 300 Micro
(qty. of 10).
