Publication 2711-UM014B-EN-P
2-4 Applying Power and Resetting Terminal
Connecting DC Power
The L1 versions (Cat. No. 2711-K5A1L1, -T9C1L1) of the PV300, PV300
Micro, PV550, PV600, PV900, and PV1000 terminals connect to a 24V
dc power source.
The table below shows the electrical ratings for the DC versions of the
terminals. Electronic circuitry and an internal fuse protect the
terminals from reverse polarity and over-voltage conditions.
Terminal Type
Supply Voltage
(24V dc nominal)
Power Consumption
PV300 Micro 11 to 30V dc 2.5 Watts max. (0.105A @ 24V
dc)
PV300 18 to 32V dc 10 Watts max. (0.42A @ 24V
dc)
PV550 18 to 30V dc 18 Watts max. (0.75A @ 24V
dc)
PV550
(touch only)
18 to 32V dc 18 Watts max. (0.75A @ 24V
dc)
PV600 18 to 32V dc 34 Watts max. (1.4A @ 24V dc)
PV600
(touch only)
18 to 32V dc 17 Watts max. (0.71A @ 24V
dc)
PV900M 18 to 30V dc 58 Watts max. (2.5A @ 24V dc)
PV900C 18 to 32V dc 50 Watts max. (2.1A @ 24V dc)
PV1000G 18 to 32V dc 40 Watts max. (1.7A @ 24V dc)
PV1000C 18 to 32V dc 50 Watts max. (2.1A @ 24V dc)
ATTENTION
!
Do not connect a DC rated PanelView terminal to an
AC power source. Connecting to an AC power
source may damage the terminal.
IMPORTANT
The PanelView terminals are designed for safe use
when installed in a NEMA Type 12, 13, NEMA 4X
(indoor use only), IP54 or IP65 rated enclosure.
ATTENTION
!
Use only a safety extra-low voltage (SELV) power
supply as a source for the PanelView 300 Micro,
PanelView 300 or 550 touch screen terminal. A SELV
power supply does not exceed 42.4V dc
To Next Page
