Atlas Copco CA2500 User Manual

Technical specifications
4812160001_A.pdf 2014-08-25
Dimensions, side view
Dimensions mm inDimensions mm in
A Wheelbase, drum and wheel 2840 112A Wheelbase, drum and wheel 2840 112
L Length, standard equipped roller 5560 219L Length, standard equipped roller 5560 219
H Height, with ROPS/cab 2810 111H Height, with ROPS/cab 2810 111
D Diameter, drum (D) 1500 59D Diameter, drum (D) 1500 59
S Thickness, drum amplitude, Nominal (D) 25 0.87S Thickness, drum amplitude, Nominal (D) 25 0.87
K1 Clearance, tractor frame 320 13K1 Clearance, tractor frame 320 13
K2 Clearance, drum frame 430 17K2 Clearance, drum frame 430 17
16
