Atlas Copco CA2500 User Manual

Machine description
4812160001_A.pdf2014-08-25
No Designation Symbol FunctionNo Designation Symbol Function
29 Gear position switch, Dip Activates the four different gear positions. (1) Hare, (2)
Drum spin, (3) Wheelspin and (4) Tortoise. The current
gear position is shown in the display by means of the
following figures.
29 Gear position switch, Dip Activates the four different gear positions. (1) Hare, (2)
Drum spin, (3) Wheelspin and (4) Tortoise. The current
gear position is shown in the display by means of the
following figures.
1: Transport mode1: Transport mode
2: Used if the drum is slipping.2: Used if the drum is slipping.
3: Used if the rear tires are slipping.3: Used if the rear tires are slipping.
4: Working mode.4: Working mode.
30 Reserve30 Reserve
31 Amplitude selector (DCO) Only for machine equipped with "Compaction
Optimizer".
31 Amplitude selector (DCO) Only for machine equipped with "Compaction
Optimizer".
35 Service socket Diagnostic socket.
Gateway is connected here to read the CAN-Open
system.
35 Service socket Diagnostic socket.
Gateway is connected here to read the CAN-Open
system.
Warning indication - membrane panel (Keypad)
"Yellow" - Warning"Yellow" - Warning
- The engine has an alarm in category yellow (Alarm image shown in the display)- The engine has an alarm in category yellow (Alarm image shown in the display)
- Communication with the display is interrupted- Communication with the display is interrupted
- The fuel level is below <10%- The fuel level is below <10%
- Charging absent- Charging absent
"Red" - Warning Flashes red continuously"Red" - Warning Flashes red continuously
- The engine has an alarm in category red (Alarm code shown in the display)- The engine has an alarm in category red (Alarm code shown in the display)
- Communication with the engine is interrupted- Communication with the engine is interrupted
- The engine temperature is too high- The engine temperature is too high
- Low oil pressure in the engine- Low oil pressure in the engine
- The air filter is clogged- The air filter is clogged
- The hydraulic fluid temperature is too high- The hydraulic fluid temperature is too high
- The hydraulic fluid filter is clogged- The hydraulic fluid filter is clogged
35
