Atlas Copco CA2500 User Manual

Technical specifications
4812160001_A.pdf2014-08-25
General
EngineEngine
Manufacturer/Model Cummins QSB 3.3 Water-cooled turbo dieselManufacturer/Model Cummins QSB 3.3 Water-cooled turbo diesel
Power output (SAE J1995), 2200 rpm 82kW (IIIA/T3, IIIB/T4i)Power output (SAE J1995), 2200 rpm 82kW (IIIA/T3, IIIB/T4i)
Engine speedEngine speed
- idling 900 rpm- idling 900 rpm
- loading/unloading 1600 rpm- loading/unloading 1600 rpm
- work/transport 2 200 rpm- work/transport 2 200 rpm
The new Tier 4i/Stage IIIB Cummins engines require the use of Ultra Low Sulphur
Diesel (ULSD) fuel, which has a sulphur content of 15 ppm (parts per million) or less.
A higher sulphur content will cause operating problems and put the useful life of
components at risk, which can lead to engine trouble.
The new Tier 4i/Stage IIIB Cummins engines require the use of Ultra Low Sulphur
Diesel (ULSD) fuel, which has a sulphur content of 15 ppm (parts per million) or less.
A higher sulphur content will cause operating problems and put the useful life of
components at risk, which can lead to engine trouble.
Tire Tire dimensions Tire pressureTire Tire dimensions Tire pressure
Flotation 550/60-22.5 TL- 12 ply 180 kPa (1.8 kp/cm) (26 psi)Flotation 550/60-22.5 TL- 12 ply 180 kPa (1.8 kp/cm) (26 psi)
The tires are liquid filled (extra weight up to 350
kg/tire, 770 lbs/tire).
During service, be aware of the extra weight that
this causes.
The tires are liquid filled (extra weight up to 350
kg/tire, 770 lbs/tire).
During service, be aware of the extra weight that
this causes.
(Anti-freeze to -30°C (-22°F))(Anti-freeze to -30°C (-22°F))
Electrical systemElectrical system
Battery 24V (2x12V 74Ah)
Battery 24V (2x12V 74Ah)
Alternator Cummins 24V 60AAlternator Cummins 24V 60A
Fuses See the Electrical system section -
fuses
Fuses See the Electrical system section -
fuses
Hydraulic system
Opening pressure MPaOpening pressure MPa
Drive system 42.5Drive system 42.5
Supply system 2.2Supply system 2.2
Vibration system 37Vibration system 37
Control systems 20Control systems 20
Brake release 1.7Brake release 1.7
Hydraulic fan system 19Hydraulic fan system 19
19
