Atlas Copco CA2500 User Manual

Maintenance - Lubricants and symbols
4812160001_A.pdf2014-08-25
Maintenance - Lubricants and symbols
Always use high-quality lubricants and the
amounts recommended. Too much grease or
oil can cause overheating, resulting in rapid
wear.
Always use high-quality lubricants and the
amounts recommended. Too much grease or
oil can cause overheating, resulting in rapid
wear.
Fluid volumesFluid volumes
Rear axle (Limited Slip)Rear axle (Limited Slip)
- Differential 3,8 liters 4.0 qts- Differential 3,8 liters 4.0 qts
- Planetary gear 0,7 liters/side 0.74 qts/side- Planetary gear 0,7 liters/side 0.74 qts/side
- Pinjong 0,3 liters 0.32 qts- Pinjong 0,3 liters 0.32 qts
Rear axle (No-Spin), (optional)Rear axle (No-Spin), (optional)
- Differential 8,3 liters 8.8 qts- Differential 8,3 liters 8.8 qts
- Planetary gear 0,65 liters/side 0.69 qts/side- Planetary gear 0,65 liters/side 0.69 qts/side
DrumDrum
- Drum gear 2,5 liters 2.6 qts- Drum gear 2,5 liters 2.6 qts
- Drum cartridge 2,2 liters/side 2.3 qts/side- Drum cartridge 2,2 liters/side 2.3 qts/side
Hydraulic reservoir 41 liters 10.8 galHydraulic reservoir 41 liters 10.8 gal
Oil in hydraulic system 80 liters 21.1 galOil in hydraulic system 80 liters 21.1 gal
Diesel engineDiesel engine
- Lubricating oil 7 liters 7.4 qts- Lubricating oil 7 liters 7.4 qts
- Coolant, without cab (IIIA/T3) 21,5 liters 22.7 qts- Coolant, without cab (IIIA/T3) 21,5 liters 22.7 qts
- Coolant, without cab (IIIB/T4i) 22 liters 23.3 qts- Coolant, without cab (IIIB/T4i) 22 liters 23.3 qts
- Coolant, with cab (IIIA/T3) 23,5 liters 24.8 qts- Coolant, with cab (IIIA/T3) 23,5 liters 24.8 qts
- Coolant, with cab (IIIB/T4i) 24 liters 25.4 qts- Coolant, with cab (IIIB/T4i) 24 liters 25.4 qts
Other fuel and lubricants are required when
operating in areas with extremely high or
extremely low ambient temperatures. See the
‘Special instructions’ chapter, or consult
Dynapac.
Other fuel and lubricants are required when
operating in areas with extremely high or
extremely low ambient temperatures. See the
‘Special instructions’ chapter, or consult
Dynapac.
ENGINE OIL Air temperature -15°C - +50°C
(5°F-122°F)
AtlasCopco Engine
100, API CJ-4 or
equivalent.
P/N 5580020624 (5 litres),
P/N 5501522700 (20 litres)
ENGINE OIL Air temperature -15°C - +50°C
(5°F-122°F)
AtlasCopco Engine
100, API CJ-4 or
equivalent.
P/N 5580020624 (5 litres),
P/N 5501522700 (20 litres)
HYDRAULIC FLUID Air temperature -15°C - +50°C
(5°F-122°F)
AtlasCopco Hydraulic
300 or equivalent.
P/N 9106230330 (20 litres),
P/N 9106230331 (209 litres)
HYDRAULIC FLUID Air temperature -15°C - +50°C
(5°F-122°F)
AtlasCopco Hydraulic
300 or equivalent.
P/N 9106230330 (20 litres),
P/N 9106230331 (209 litres)
Ambient air temperature above
+40°C (104°F)
Shell Tellus S2 V100 or
equivalent.
Ambient air temperature above
+40°C (104°F)
Shell Tellus S2 V100 or
equivalent.
85
