AudioCodes Mediant 3000 Installation Manual

Installation Manual 24 Document #: LTRT-94704
Mediant 3000 & IPmedia 3000
2.5.1 LEDs
The 6310 blade provides LEDs that are located on its front panel (as shown in ''6310 Blade''
on page 22).
These LEDs provide an indication of the various operational statuses of the
blade, as described in the tables below.
Notes:
• The PSTN LEDs are applicable only to Mediant 3000; IPmedia 3000
provides only IP interface.
• The PSTN C LEDs are applicable only to T3 interface.
• The ATM LEDs are not applicable in this current release.
Table 2-7: Blade Status LEDs Description
Label Color Status Description
FAIL Red
On Blade failure (fatal error).
-
Off Normal operation.
ACT Green
On Active blade.
Note: Applicable only to Mediant 3000 HA.
Yellow
Blinking Redundant blade in standby mode.
Note: Applicable only to Mediant 3000 HA.
-
Off Standalone blade (i.e., in Simplex mode).
Table 2-8: Gigabit Ethernet (GBE) LEDs Description
Label Color Status Description
LINK/ACT
1 and
LINK/ACT
2
Green
On Ethernet link is established.
Blinking Data is transmitted or received.
Yellow
On Protection (redundant) link is established.
-
Off No Ethernet link.
