Installation Manual 80 Document #: LTRT-94704
Mediant 3000 & IPmedia 3000
10. Click OK; the ‘Client Configuration’ screen closes.
11. Physically reset the device using the hardware reset button (or power down and then
power up the device). This causes the device to use BootP; the device changes its
network parameters to the values provided by BootP.
Figure 5-2: BootP Client Configuration Screen
5.1.3 Assigning an IP Address using the CLI
You can assign an IP address to the device, using command-line interface (CLI).
¾ To assign an IP address via the CLI (if supported):
1. Connect the device's RS-232 port (located on the blade) to either COM1 or COM2
communication port on your PC (refer to “Connecting the RS-232 Port to a PC” on
page 62).
2. Use a serial communication software (e.g., HyperTerminal
TM
) to establish a serial
communication link with the device, using the following communications port settings:
• Baud Rate: 115,200 bps
• Data Bits: 8
• Parity: None
• Stop Bits: 1
• Flow Control: None
The CLI prompt appears.
3. At the prompt, type conf, and then press <Enter>; the configuration folder is
accessed.
4. To view the current network parameters, at the prompt, type GCP IP, and then press
<Enter>; the current network settings are displayed.
