Installation Manual 38 Document #: LTRT-94704
Mediant 3000 & IPmedia 3000
2.9.1 AC Power System
The AC power system is powered from two AC sources (providing 1+1 power redundancy)
and consists of the following hardware components:
Power Entry Module (PEM/AC/3K)
Power Supply Module (PS/AC/3K)
The table below lists the device's AC power specifications.
Table 2-18: AC Power Supply Specifications
Parameter Value
Power Requirements
Universal 100-240 VAC input at a nominal 50/60 Hz line frequency
Power Consumption
Depends on installed blade and configuration:
TP-6310 Simplex:
9 2.1A @ 110VAC, 226W
9 1A @ 230VAC, 226W
TP-6310 HA:
9 3.2A @ 110VAC, 356W
9 1.5A @ 230VAC, 356W
TP-8410 Simplex 63 E1/84 T1:
9 1.95A @ 110VAC, 215W
9 0.95A @ 230VAC, 215W
TP-8410 HA 63 E1/84 T1:
9 3A @ 110VAC, 322W
9 1.4A @ 230VAC, 322W
Connection Provisions
PEM module with 3-prong AC inlet
Note:
Currently, the AC power option is supported only by Mediant 3000.
2.9.1.1 AC Power Entry Modules
The device's chassis is supplied with two PEM/AC/3K Power Entry Modules (PEM)
modules (housed in its rear panel), for connecting the device's chassis to AC power
sources. The dual PEMs allow connection to two independent AC power sources, providing
electrical input (power) redundancy in the event of an AC power source failure. The device
uses complete power entry separation between the two existing AC power supplies in the
system.
