Barco DP2K-S Series User Manual

15. Removal and installation of the projector covers
15.4 Removal of the left side cover
WARNING: Switch off the projector prior to start with this procedure, unless otherwise specified in the pro -
cedure.
Necessary tools
7mm fl at screwdriver.
How to remove the left side cover?
1. R elease the small dust filter assembly from the front side of the projector. U se 7m m flat screw driver to loosen the captive screw
(reference 1 image 15-4) of the sm all dust filter assembly.
Note: The left side cover is partial captured by the sheet metal of the small filter assem bly. For that, this filter has to be (partially)
removed first.
1
Image 15-4
2. L oosen the five captive screws (reference 2 image 15-5) of the left s ide cover using a 7mm flat screwdriver.
3. R emov e t he left side cover from the projector.
2
1
Image 15-5
R5977692 DP2K-S SERIES 10/12/2012 121
