15. Removal and installation of the projector covers
15.7 Installation of the side cover plate of the Light Processor compartment
Necessary tools
3mm Allen wrench.
How to install the si de cover plate from the Light Processor compartment?
1. Place the s ide c over plate into position as illustrated. Ensure that all 12 s lots of the side cover plate are engaged (three at each
side).
2
1
C
B
B
A
C
Image 15-9
2. Fas ten the side cove r plate with a screw a
t the top (reference 1 image 15-9) and the two screws at the bottom (reference 2
image 15-9). Us e a 3mm Allen wrench.
CAUTION: O pening the Light Processo r com partm ent by removing the top cover plate or side cover plate will
result in a tamper even t. An authorization to clear t he security w arn ing on the projector, af ter closing off the
Light Processor compartmen t, will be n eeded !
R5977692 DP2K-S SERIES 10/12/2012 125
