15. Removal and installation of the projector covers

15.11 Installation of the rear cover

Necessary tools

7mm ﬂ at screwdriver.

How to install the rear cover?

1. Install the rear c over on the projector.

2. Fas ten the four captive screws (reference 1 image 15-15) of the rear cover using a 7mm ﬂat screwdriver.

Image 15-15
