12. Lamp House & Lamp replacement
12.2 Supported x enon lamps
Cathode adaptor
A cathode adaptor is required to mount the xen on lamp in the Lamp House. The catho de adapter has to be mounted o n the cathode
side of the xenon lamp prior to mounting the lam p in to the Lamp House. The purpose of the c athode adapter is to position the arc
of the xenon lamp in the middle o f the reflector inside the Lamp House. Note that there is no anode adaptor for the Lamp House of
the D P2K -S series projector.
Image 12-4
Cathode adapter (R858100K)
All lamp s and adapters in the table below can b e u sed in the L amp House of the DP2 K-S series p rojector. Note
that the maximum lamp power the projector delivers dep ends o n the type of p rojector and t he installed lamp.
Prior to install the lamp it’s important to check with the Comm unicator software if the lam p is listed in the list
of s upporte d lamps for thi s pr ojector.
Supported lamp types and cathode adapter:
Lamp type & Supplier Cathode adapter Barco O rder N o. DP2K–10S series
USHIO 1.2kW DXL12BAF
R858100K R9855961 Yes
USHIO 1.6kW DXL16BA
R858100K R9855972 Yes
USHIO 2.0kW DXL20BAF
R858100K R9855955 Yes
USHIO 2.0kW DXL20BAF2
R858100K R9855965 Yes
USHIO 2.0kW DXL20BAF/L
R858100K R9801067 Yes
USHIO 2.2kW DXL22BA
R858100K R9855971 Yes
OSRAM 1.2kW DHP
R858100K R9855959 Yes
OSRAM 2.0kW DHP
R858100K R9855956 Yes
PHILIPS 2.0kW X DC2000B
R858100K R9801071 Yes
The table above is subject to changes and was last updated on 15 October 2012. Consult https:// my. barco.com
for the most recent information about supported lamps for the DP2K-S series projector.
WARNING: Always use the correct Cathode adapter for the xenon lamp in the Lamp House. Neglecting this
may result in poor performance of the lamp and damage to the x enon lamp and Lamp House. Some adapters
looks the same, therefore check the engraved item nu mb er u pon the ad apter t o ensure yo u use the right
adapter.
80 R5977692 DP2K-S SERIES 10/12/2012
