A. Specifications
A.2 Dimensions of the DP2K-S series projector
Dimensions
POINT OF
GRAVITY
TOP FIXATION
POINTS M10
779,5
499
49
364
182
max. 150
min. 41,5
431,4
370,5
200
66
369
252,5
188,4
max lens
extension 97
min lens
retraction 38
656
927
224,4
91
757,5
91
141
100,3
316,6
626
113
Image A-1
Dimens ions giv en in millimeters.
R5977692 DP2K-S SERIES 10/12/2012 135
