Chapter 5: Operation
5. Click on a selected switch macro with the right mouse button to create a copy
of the current switch macro using the option “Save as....”
6. You can delete already saved macros by pressing the “Delete” symbol.
To load a predefined switching, proceed as follows:
1. Select the switch macro in the right column of the working area that has to be
loaded.
2. Activate the selected switch macro by pressing the “Send” button on the
bottom right of the working area.
NOTES:
A predefined switch macro can only be activated in on-line mode.
When loading presets, only the switching operations that are compliant with the
hardware and the configuration of the currently used matrix are taken into
account.
5.8 Serial Interface
Figure 5-13. OSD icon.
The ServSwitch DKM FX enables you to switch via a serial interface (RS-232).
Detailed information for the serial interface and the corresponding switching
commands can be found in Chapter 6.
5.9 Power On and Power Down Functions
The ServSwitch DKM FX has the following power on and power down functions:
restart and reset.
5.10.1 Restart
To perform a restart, use OSD or Java.
Figure 5-14. OSD icon.
