Chapter 2: Overview
2.5.8 ServSwitch DKM FX Compact 16-Port Fiber (ACXC16F)
1 2 3
Figure 2-10. Front view, ACXC16F.
Table 2-12. ACXC16F components.
Number Component
1 I/O ports 1–16 (SFP)
2 Serial connection (RJ-45)
3 Network connection (RJ-45)
1 2 3
Figure 2-11. Back view, ACXC16F.
Table 2-13. ACXC16F back-panel components.
Number Component
1 Power supply unit 1
2 Power supply unit 2
3 Grounding
