Chapter 2: Overview
2.5.10 ServSwitch DKM FX Compact 32-Port Fiber (ACXC32F)
1 2 4
Figure 2-14. Front view, ACXC32F.
Table 2-16. ACXC32F components.
Number Component
1 I/O ports 1–16 (SFP)
2 I/O ports 17–32 (SFP)
3 Serial connection (RJ-45)
4 Network connection (RJ-45)
1 2 3
Figure 2-15. Back view, ACXC32F.
Table 2-17. ACXC32F back-panel components.
Number Component
1 Power supply unit 1
2 Power supply unit 2
3 Grounding
3
