Chapter 2: Overview
2.5.7 ServSwitch DKM FX Compact 16-Port (ACXC16)
1 2 3
Figure 2-8. Front view, ACXC16.
Table 2-10. ACXC16 components.
Number Component
1 I/O ports 1–16 (CATx)
2 Serial connection (RJ-45)
3 Network connection (RJ-45)
1 2 3
Figure 2-9. Back view, ACXC16.
Table 2-11. ACXC16 back-panel components.
Number Component
1 Power supply unit 1
2 Power supply unit 2
3 Grounding
