724-746-5500 | blackbox.com
Chapter 2: Overview
2.6 Diagnostics and Status
2.6.1 Status LEDs
The ServSwitch DKM FX and DKM FX Compact LED indicators are shown in
Figures 2-12 through 2-22, and described in Tables 2-14 through 2-25.
1
2
Figure 2-32. CPU board, front view.
