5. Refer to the following table to confirm the number on the Platen (a) that corresponds to the size of paper for print-
ing.
Number Dimensions Paper Size
2 254 mm (10 in) or 257 mm 10"x12", 8"x10", or JIS B4
3 355 mm (14 in) 14"x17"
4 406 mm (16 in), 420 mm, or 432 mm (17 in) 16-in. Roll (406.4mm), ISO A2, 17-in. Roll (431.8mm), or
ANSI C
5 515 mm (20 in) JIS B2 or JIS B3
6 610 mm (24 in) ISO A1, ISO A2, or 20"x24"
6. Using the back of the Cleaning Brush, move the Switch to the side opposite ●, corresponding to the size of the paper
for printing.
In this case, note that you will move the switch in the opposite direction from the direction in step 4.
7. Close the Top Cover.
Troubleshooting
>
Problems with the printing quality
>
iPF6300S Setting the Blue Switch on the Platen
