14
Use the included charger to charge the battery. Be sure to charge the battery
as it is not charged at the time of purchase.
Remove the cover.
Insert the battery.
● Align the S marks on the battery and
charger, then insert the battery by sliding it
in and down .
Charge the battery.
● For CB-2LV: Flip out the plug and plug
the charger into a power outlet .
● For CB-2LVE: Plug the power cord into
the charger, then plug the other end into a
power outlet.
X The charge lamp lights red and charging
starts.
● The charge lamp will light green when
charging has finished. Charging takes
approx. 1 hour and 30 minutes.
Remove the battery.
● Unplug the battery charger from the power
outlet, then remove the battery by sliding it
in and up .
To protect the battery and prolong its life, do not charge it for longer than
24 hours continuously.
EC277_CUG-E_CDP-E078.book Page 14 Thursday, May 21, 2009 8:16 PM
