Select the checkbox to display the Analytics+ rules in the live view
interface.
This function is for some series products only.
Click Setting and select the channel to restore the corresponding
channel image to the original scale.
Configure audio input on live view. You can select Audio 1, Audio 2,
and Mixing. For example, if you select Audio 1 for D1 channel, the
sound of audio input port 1 of camera is playing. If you select
Mixing, the sound of all audio input ports are playing.
Support 1920×1080, 1280×1024(default), 1280×720.
Step 3 Click Apply.
5.16.2 Tour
Background Information
You can configure a tour of selected channels to repeat playing videos. The videos display in
turn according to the channel group configured in tour settings. The system displays one
channel group for a certain period and then automatically changes to the next channel
group.
Procedure
Step 1 Select DISPLAY > Tour Setting > Main Screen.
