To Next Page

To Previous Page

Enter/Exit Programming Mode

110 QuickScan™ I QD24XX

TRIOPTIC CODE

The following options apply to the Trioptic symbology.

Trioptic Code Enable/Disable

DEFAULT

$CCTEN00(CR)

Trioptic Code = Disable

$CCTEN01(CR)

Trioptic Code = Enable

CODE 32 (ITAL PHARMACEUTICAL CODE)

The following options apply to the Code 32 (Italian Pharmaceutical Code) symbology.

Code 32 Enable/Disable

When disabled, the reader will not read Code 32 bar codes.

DEFAULT

$CP3EN00(CR)

Code 32 = Disable

$CP3EN01(CR)

Code 32 = Enable
