Enter/Exit Programming Mode
156 QuickScan™ I QD24XX
GS1 DataBar™ Expanded Set Length 2
This feature specifies one of the bar code lengths for GS1 DataBar™ Expanded Length Control. Length 2 is the
maximum label length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length
includes the bar code’s data characters only. The length can be set from 1 to 74 characters. A
setting of 0 specifies
to ignore this length (only one fixed length).
Ta bl e 18 provides examples for setting Length 2. See page 217 for detailed instructions on setting this feature.
Table 18. GS1 DataBar™ Expanded Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (ignore sec-
ond length)
07 Characters 52 Characters 74 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT GS1 DataBar™ EXPANDED LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ and ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
Select GS1 DataBar™ Expanded Set Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
74 = Length 2 is 74 Characters
To Next Page
