Enter/Exit Programming Mode
190 QuickScan™ I QD24XX
PDF417 Set Length 2
This feature specifies one of the bar code lengths for PDF417 Length Control. Length 2 is the maximum label
length if in Variable Length Mode, or the second fixed length if
in Fixed Length Mode. Length includes the bar
code’s check, data, and full-ASCII shift characters. The length does not include start/stop characters. Characters
can be set from 01 to 2,710 characters (pad with zeroes) in increments of 01. Any value greater than 2,710 will be
considered to be 2,710.
See page 217 for detailed instructions on setting this feature.
Select PDF417 Length 2 Setting
To configure this feature, scan
the ENTER/EXIT PRO-
GRAMMING MODE bar code above, then the bar code
at
left followed by the digits from the Alphanumeric
characters in
Appendix D, Keypad representing your
desired character(s). End by scanning the ENTER/EXIT
bar c
ode again.
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
Length 2 is 2,710 Characters
