118 QuickScan™ I QD24XX
Code 128 Set Length 2
This feature specifies one of the bar code lengths for Code 128 Length Control. Length 2 is the maximum label
length if in Variable Length Mode, or the second fixed length if in Fixed Length Mode. Length includes the bar
code’s data characters only.
The length can be set from 1 to 80 characters. A setting of 0 specifies to ignore this length (only one
fixed length).
Ta bl e 6 provides examples for setting Length 2. See page 217 for detailed instructions on setting this feature.
Table 6. Code 128 Length 2 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting
00 (Ignore This
Length)
07 Characters 15 Characters 80 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT CODE 128 LENGTH 2 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘0’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘8’ and 0’
5 Scan ENTER/EXIT PROGRAMMING MODE
.
Select Code 128 Length 2 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
CANCEL
DEFAULT
80 = Length 2 is 80 Characters
To Next Page
